Adarsh Nickel Alloys stands out as a top manufacturer and supplier of Titanium Tube Fittings in Delhi, providing expertly crafted components for high-performance piping and tubing systems. Made from high-quality titanium and titanium alloys, these fittings boast impressive corrosion resistance, strength, and durability. Adarsh Nickel Alloys adheres to rigorous quality control measures and international standards to guarantee leak-free performance and precise dimensions. Catering to industries like aerospace, chemical processing, marine, oil & gas, power generation, and medical sectors, the company offers titanium tube fittings that consistently perform well under extreme pressure, temperature, and corrosive conditions.
Titanium Tube Fittings are crafted from commercially pure titanium or titanium alloys, including Grade 2 and Grade 5 (Ti-6Al-4V). This blend provides outstanding corrosion resistance, especially against seawater, chlorides, and aggressive chemicals. On the mechanical side, titanium fittings showcase high tensile strength, excellent fatigue resistance, and remarkable toughness while remaining lightweight. They maintain their mechanical stability across a broad temperature range and offer good weldability and formability, making them ideal for precision tubing systems and high-pressure applications.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloy Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Tube Fittings find their place in various applications where corrosion resistance, strength, and reliability are paramount. They are frequently used in chemical processing facilities, marine and offshore setups, and oil & gas piping systems. In the aerospace sector, these fittings are essential for hydraulic, fuel, and cooling lines. Additionally, they are utilized in power generation, desalination plants, medical devices, and pharmaceutical processes.
