Adarsh Nickelalloys is a trusted manufacturer and supplier of high-quality Nimonic 90 Sheets and Plates in Delhi, India. Nimonic 90 is a nickel-based superalloy known for its excellent strength, oxidation resistance, and high-temperature stability, making it suitable for demanding applications in aerospace, gas turbines, and industrial sectors. These sheets and plates provide superior performance under extreme conditions, offering excellent mechanical properties such as high tensile strength and resistance to creep. We offer a wide range of Nimonic 90 products tailored to meet specific customer requirements, ensuring the highest standards of quality and reliability.
**Nimonic 90** is a superalloy made from nickel, chromium, and cobalt, designed to be precipitation-hardenable. It features a balanced nickel content, along with 18–21% chromium, 15–21% cobalt, 2–3% titanium, and 1–2% aluminum, plus trace amounts of carbon, silicon, and other elements that boost its performance. ([Quest 4 Alloys][1]) This alloy boasts impressive mechanical properties, including high tensile strength, excellent creep resistance, and good ductility, even at elevated temperatures of up to about 920 °C. ([Quest 4 Alloys][1]) Nimonic 90 also shows strong yield strength and elongation, making it ideal for demanding engineering applications where both strength and heat resistance are essential. ([Quest 4 Alloys][1])
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
**Nimonic 90 sheets and plates** are perfect for high-temperature and high-stress environments, thanks to their exceptional strength, oxidation resistance, and creep resistance. ([Alloys International][2]) They find extensive use in aerospace components, including turbine blades, combustion chambers, and hot section parts of jet engines. ([Alloys International][2
