Adarsh Nickel Alloys is a trusted manufacturer and supplier of high-quality Inconel 625 Flanges in Delhi, offering dependable solutions for critical piping and pressure systems. These flanges are manufactured using premium-grade raw materials and precision forging and machining techniques to ensure excellent dimensional accuracy, strength, and leak-proof performance. Inconel 625 is widely known for its outstanding resistance to corrosion, oxidation, and extreme temperatures. With strict quality control and a customer-focused approach, Adarsh Nickel Alloys supplies Inconel 625 Flanges that meet international standards and perform reliably in demanding industrial environments.
| Standards | GOST Flange, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092, BS, BS4504, BS 10, EN-1092, DIN, ANSI, ASME, DIN, MSS S44, ISO70051, ANSI/ASME B16.5, ASME/ANSI B16.5/16.36/16.47A/16.47B, B16.47 Series A & B, B16.48, EN |
|---|---|
| Pressure Rating ANSI | Class 1500, Class 150, Class 900, Class 2500, Class 300, Class 600, |
| Pressure Calculation in DIN | 10Bar, 16Bar, 25Bar, 40Bar, 6Bar, / PN16, PN64, PN40, PN25, PN10, PN6 |
| JIS | 16 K, 20 K, 5K, 10 K, 40 K, 63 K, 30 K, |
| UNI | 10Bar 16Bar 6Bar 25Bar 40Bar |
| EN | 6Bar 25Bar 40Bar 10Bar 16Bar |
| Most common Types | Threaded / Screwed / Forged / Plate |
| Production technique | Forged, Heat treated and machined |
| Shapes and Types we produce | Large Male-Female (LMF), Ring Type Joint (RTJ), Flat Face (FF), Small Tongue, Small Male-Female (SMF),Raised Face (RF), Large Tongue & Groove, Groove, Lap-Joint Face (LJF) |
| Test | Direct-reading Spectrograph, Magnetic particle detector, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector |
| Equipment | Pushing Machine, Press machine, Bending machine, Sand-blasting machine, electric bevelling machine etc |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Inconel 625 | 8.4 g/cm3 | 1350 ?C (2460 ?F) | Psi ? 1,35,000 , MPa ? 930 | Psi ? 75,000 , MPa ? 517 | 42.5 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | ? | 5.0 max | 58.0 min | 20.0 ? 23.0 |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Flanges in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Flanges supplied by Adarsh Nickel Alloys are widely used in oil and gas, petrochemical, chemical processing, marine, and power generation industries. They are commonly applied in offshore pipelines, heat exchangers, pressure vessels, and high-temperature piping systems. These flanges are also suitable for nuclear facilities and seawater applications where corrosion resistance is critical. Their excellent mechanical strength, resistance to aggressive media, and long-term reliability make Inconel 625 Flanges an ideal choice for critical industrial applications.
